- Size: small
- Place of Origin: Beijing
- Brand Name: Raybaca
- Model Number: RBC-PDA707
- Weight: 1.000 kg
Raybaca livestock readers quickly and easily capture unique identification information, helping farmers and ranchers make quick work of herd management. Given our expertise in livestock identification systems, it’s only natural that we also provide a variety of versatile readers. Our RFID devices are developed and produced in-house, and each reader is suited to a different environment, but can be used on a variety of species. With stationary and portable options, and mountable chute/sweep/gate readers we’re sure to have something that will suit your needs for use indoors or outdoors.
Function module | Classify module |
Barcode | 1D red light barcode |
1D laser barcode | |
2D barcode | |
Antecedent module | RFID full-band |
Ethernet card (KHz) | |
Outer joint | RS232 |
RS485 | |
GPS | GPS |
PSAM | 2 Slot |
Model | RBC707W-LOS-1HLG |
CPU | HF1.2GHz, 4-core Processor |
Memory | ROM8G, RAM1G, Max Capacity:32G |
Network | WCDMA:GSM、GPRS、EDGE、UMTS、HSDPA;EVDO:IS-95A/B、1XEVDO Rev.0/Rev.A |
Screen | 4.0inch,ISP screen, high definition on sunshine |
Scanning | Scanning Barcode and 2-dimension code |
HF RFID(Optional) | 13.56MHz, conform to ISO14443A/B,ISO15693, Support NFC protocol |
UHF RFID(Optional) | 900MHz, conform to ISO-18000,6C,EPC Protocol. Matching two antennas (optional round or length) |
Ethernet | With built-in network adapter, standard Ethernet RJ45joint ,Support Ethernet and static IP/DHCP protocol, support PPPoE dial and internet. |
Outer joint | RS232/RS458 |
Keyboard | Button, Off-hook, on-hook, flashlight, cameral and the standard keyboard in the Android system. |
GPS | Support GPS |
Bluetooth | Bluetooth 2.1;802.11a/b/g |
Encryption joint | Two card slots of PSAM,Support ISO7816 protocol |
Battery | 6000Mah lithium ion battery |
Hardware expandability | 433MHz, 2.4GHz,134KHz,125KHz reading-writing module ZigBee communication module Sensor communication module |
