- Size: small
- Place of Origin: Beijing
- Brand Name: Raybaca
- Model Number: RBC-PDA708
- Weight: 1.000 kg
Raybaca livestock readers quickly and easily capture unique identification information, helping farmers and ranchers make quick work of herd management. Given our expertise in livestock identification systems, it’s only natural that we also provide a variety of versatile readers. Our RFID devices are developed and produced in-house, and each reader is suited to a different environment, but can be used on a variety of species. With stationary and portable options, and mountable chute/sweep/gate readers we’re sure to have something that will suit your needs for use indoors or outdoors.
Function | ||
CPU | Cortex-A7,4-core,1.3GHZ processor | |
Memory | ROM：EMMC 16GB RAM： LPDDR3 1GB | |
System | Android 4.42 | |
Wireless set | GPRS | GPRS, EDGE , 4-band 900/1800，850/1900 |
WCDMA | band 850/1900/2100，Cat.8 HSDPA Cat.6 HSUPA | |
WIFI | IEEE 802.11b/g | |
Bluetooth | Bluetooth 4.0 | |
Screen | 7 inch IPS screen, 1024*600 resolution,Full view | |
Touch screen | Support multi touch capacitive touch and glove operation | |
Indicator light | WLAN light,charge display light | |
Audio | Support voice output | |
Micro SD card | Support 32GB MICRO SD card | |
Data protection | Prevent data loss from off power | |
GPS | 12 channel | |
Receive type: L1，C/A code，phase smoothing With carrier | ||
Recapture: <1s | ||
Newest ASIC chip,COAST algorithm,EVEREST technology | ||
Navigation Map | Support Careland,Baidu,Google,Amap | |
Input | Full screen handwriting,The handwriting screen,Digital, symbols,etc | |
Physical interface | High fast USB2.0 device interface，3.5 recharge interface | |
Camera(optional) | Face 200W.behind 500W,with flash lamp | |
Hand light | Low power LED light,emergency use | |
Fingerprint model(optional) | Inductance type,Image 256*288, 500 DPI | |
Registration time <3s;Contrast time <0.1s;Comparison time<0.5s, | ||
Fingerprint number: 500 | ||
One dimensional bar code | ||
Read | Can read kinds of code:Code 39、Code 93、Code 128、Codebar、EAN-13、EAN-8、UPC-A、UPC-E、ITF 14、UCC/EAN-128、ITF 25、Matrix 25、EAN-128、ISBN | |
Read distance | 0~55 cm | |
Read rate | First read>99%;Error rate<0.01%,Reject<0.01% | |
Two dimensional bar code | ||
Honeywell-6603 | Laser scanning,long distance, high precision, fast decoding speed, the error rate is less than 0.01% | |
RFID | ||
UHF (915MHZ) | Read the 900MHZ tag with EPC C1 GEN2 or ISO18000-6C standard | |
HF(13.56MHZ) | Read the 13.56MHZ tag with ISO15693 and ISO14443 standard | |
LF | 125KHZ/134.2KHZ animal tag | |
PSAM | Support two PASM card | |
HF(CPU card) | Support CPU card to read/write, with PSAM use | |
Active close range communication (optional) | ||
Active 2.45G | 200m distance,one time read for 200 tag | |
433M | Above 200m,distance is adjustable | |
ZIGBEE | Suit for wireless data acquisition | |
Battery feature | ||
Battery | Built-in 10000mA lithium battery;Standby time:more than 150 hour;working time:more than 12 hour;AC recharge（2A） | |
Largest standby time | More than 360 hour | |
Recharge time | Less than 4.5 hour | |
Working environment | ||
Operate temperature | -20℃~50℃ | |
Storage temperature | -20℃~70℃ | |
Relative humidity | 10%~90%RH,No condensation | |
Physical parameters | ||
Weight | Less than 500g( no include charge) | |
Device dimension | L208*W130*D20±2mm | |
Accessory | ||
Standard | One recharge head,one DC recharge wire,one USB data wire. | |
